Dual Port Coax Tap - 5 to 1000 MHz
SKU
Dual Port Coax Tap
75 Ohm | Tap Value: 8dB | Isolation out to tap: 20dB | Dual Port | Frequency Range: 5-1000MHz
Dual Port Coax Tap - 5 to 1000 MHz - 8dB
Coax taps are used when one video source feeds multiple displays in the same location. This dual port coax tap has one feed through port and two tap ports. The feed through port typically will go to the next coax tap in the line. The tap ports will be used for the displays.
Features:
- 75 Ohm
- Tap Value: 8dB
- Frequency Range: 5-1000MHz
- Tap Loss: 8 ± 1.5dB
- Insertion Loss: 4dB
- Isolation out to tap: 20dB
- Return Loss: 18dB
- All Ports F-type Female
Write Your Own Review
Features & Specs | ||
---|---|---|
Number of Taps | Number of tap ports ? | 2 |
Connector Type | The type of connectors used on this tap? | F-Type Female |
Frequency Range | Frequencies supported by this tap? | 5 to 1000MHz |
Tap Value | Attenuation of the tap port ? | 12dB |
DC Power Passing | Number of Ports that will allow DC power through the tap? | 1 Port |
